IC-QSFP-FMCa

Two QSFP+ FPGA Mezzanine Card

FMC
VITA57.1 HPC Compliant
2*QSFP+ cages
2*reference clocks

IC-QSFP-FMCa - FPGA Mezzanine Card with two QSFP+

Communication interface
Two QSFP+ cages – according to SFF-8436 standard
– for QSFP+ passive and active copper and active optical cables

Clocks
One SSMC connector for external reference clock, AC coupled and 50 Ω-terminated on-board. It can be driven by either a sine wave source (0 to 10 dBm), or a square wave source (LVPECL / CMOS)

Clock signal (SEC_REF) provided by FPGA carrier on FMC connector on HB19_P/N pins. LVDS 100 Ω differential signal and AC coupled input

Local 25 MHz crystal (optional oscillator for special frequency generation when necessary)

Board Electrical/environmental
VITA 57.1 HPC single width module
Power dissipation: around 5W including the consumption of two QSFP+ optical cables
FMC I/O voltage: VADJ=1.8V or 2.5V (factory setting)
Air cooled (Conduction cooled to be confirmed with dependency on the chosen QSFP+ cable)

IC-QSFP-FMCa - FPGA Mezzanine Card with two QSFP+ diagram

✖

Criterion	Standard	Extended	Rugged	Conduction-cooled 71°C	Conduction-cooled 85°C
Coating	Optional	Yes	Yes	Yes	Yes
Operat. Temp.	0 to 55°C	-20 to 65°C	-40°C to 71°C or 85°C (*)	-40°C to 71°C at the thermal interface (*)	-40°C to 85°C at the thermal interface (*)
Rec. airflow	1 .. 2 m/s	2 .. 3 m/s	2 .. 5 m/s	-	-
Oper. HR% no cond.	5 to 90%	5 to 95%	5 to 95%	5 to 95%	5 to 95%
Storage Temp.	-45°C to 85°C	-45°C to 85°C	-45°C to 100°C	-45°C to 100°C	-45°C to 100°C
Sinusoidal Vibr	2G [20..2000]Hz	2G [20..2000]Hz	5G [20..2000]Hz	5G [20..2000]Hz	5G [20..2000]Hz
Random Vibr	0.002g2 /Hz [10..2000]Hz	0.002g2 /Hz [10..2000]Hz	0.05g2 /Hz [10..2000]Hz	0.1g2 /Hz [10..2000]Hz	0.1g2 /Hz [10..2000]Hz
Shock 1/2 Sin. 11ms	20G	20G	40G	40G	40G

(*) Temperature grades are subject to availability according to IC products. Please consult us.
