Products

IC-INT-VMEb

6U VME Intel Xeon D-1500  Single Board Computer

  • 6U VME
  • Intel® Xeon® D-1500 processor
  • up to 16 GB DDR4 with ECC
  • up to 16 GB SATA SSD
  • Xilinx® Kintex®-7 FPGA
  • Two PMC/XMC slots

IC-INT-VMEb - 6U VME Intel Xeon D-1500  SBC

Please prefer the IC-INT-VMEc product for new designs.

The IC-INT-VMEb, powered by an Intel® Xeon D Series – Broadwell DE processor, offers unparalled performance to VME legacy applications to provide ruggedized and highly secure solutions.
The Intel ® Xeon D-1500 family brings the performance of Intel Xeon processor into a dense, low-power system on a chip. With its Intel® 64 Broadwell microarchitecture and its HyperThreading technology, the processing throughput and the application performance are greatly enhanced.

Floating point processing is drastically improved by the Advanced Vextor Extension (AVX2) Instruction Set Extension offering an ideal open system for demanding time critical applications.
The IC-INT-VMEb is delivered with its own Boot Loader. This capability to master UEFI firmware allows Interface Concept to implement specific functions of services for accurate power-up sequences.

Processor Unit
One Intel® Xeon® Processor D-1559 or D-1539 or D-1519
Core speed = 1.5 GHz for D-1559 and D-1519 ; 1.6 GHz for D-1539
Cache = 18 MB for D-1559 ; 12 MB for D-1539 ; 6MB for D-1519
Thermal design power = 45W for D-1559 ; 35W for D-1539 ; 25W for D-1519
DDR4 with ECC (up to 2*8 GB)
Boot flash memory
Calendar clock with supercap backup
Thermal monitor sensor

Storage subsystem
On-board SATA SSD (up to 16 GB)
Up to 4 * SATA ports on P0

Communication subsystem
4 * Gigabit Ethernet ports (1588, Virtualization)
4 * USB ports (1 front/ 3 rear)
1 * console port (front or rear)
3 * multimode serial ports (RS422, RS485, RS232)
HDMI/DVI output (optional)

I/O subsystem
VME64x
Two PMC/XMC slots(slot 0 compatible with VITA35 P4V2-64ac . From Pn6 12differential pairs available on P2 and upt to 8 differentail pairs available on P0)
Open FPGA (Xilinx®Kintex-7) interfaced with up to 80 differential pairs/ single ended and 4GTP lanes to an optional FMC slot.

Accessories
6U Rear Transition Module

The IC-INT-VMEb is available in air-cooled and conduction cooled (without front IO) versions compliant with VITA 47 classes.



Interface features
VMEbus 64x interface (P1/P2)
DTB Master : A16/24/32/64 ; D08-D64, SCT, BLT,
MBLT, 2eVME
DTB Slave : A16/24/32/64 ; D08-D64, SCT, BLT,
MBLT, 2eVME
Arbiter : RR/PRI/SGL
Interrupt : handler/generator with IRQ[1..7]
System controller

Front connectors:
1 * Gigabit Ethernet port (RJ45)
1 * console port
1 * USB
PMC/XMC slot 0
PCI-X up to 100MHz
PCIe x8
PMC/XMC slot 1
PCI-X up to 100MHz
PCIe x8

P0 connector
3 * Giga Ethernet (Compliant with Vita31.1)
3 * USB2
Up to 4 * Sata
1 * DVI (optional)
IOs (from Pn6)

P2 connector
Pn4 I/Os : PMC0 I/Os routed on P2 (VITA35
P4V2-64ac)
4*UARTs
I/Os (from Pn6)

Miscellaneous
IPMI (VITA 38)
HPC connector (exclusive with one PMC/XMC
slot) to connect an FMC to the FPGA.

IC-INT-VMEb - 6U VME Intel Xeon D-1500  SBC diagram
IC-INT-VMEb - 6U VME Intel Xeon D-1500  SBC diagram
Criterion Standard Extended Rugged Conduction-cooled 71°C Conduction-cooled 85°C
Coating Optional Yes Yes Yes Yes
Operat. Temp. 0 to 55°C -20 to 65°C -40°C to 71°C or 85°C (*) -40°C to 71°C
at the thermal interface (*)
-40°C to 85°C
at the thermal interface (*)
Rec. airflow 1 .. 2 m/s 2 .. 3 m/s 2 .. 5 m/s - -
Oper. HR% no cond. 5 to 90% 5 to 95% 5 to 95% 5 to 95% 5 to 95%
Storage Temp. -45°C to 85°C -45°C to 85°C -45°C to 100°C -45°C to 100°C -45°C to 100°C
Sinusoidal Vibr 2G [20..2000]Hz 2G [20..2000]Hz 5G [20..2000]Hz 5G [20..2000]Hz 5G [20..2000]Hz
Random Vibr 0.002g2 /Hz
[10..2000]Hz
0.002g2 /Hz
[10..2000]Hz
0.05g2 /Hz
[10..2000]Hz
0.1g2 /Hz
[10..2000]Hz
0.1g2 /Hz
[10..2000]Hz
Shock 1/2 Sin. 11ms 20G 20G 40G 40G 40G
(*) Temperature grades are subject to availability according to IC products. Please consult us.
