The pLinesES4-8 is a very high performance COTS communication computer solution with large opening functionalities.
It can be used in many networks or embedded communication applications such as Front end processor, low-cost embedded computer with communication capabilities or communication gateways.
Processor Unit
PPC603e with FPU 32-bit RISC architecture:
– 16KB Instruction and 16KB Data L1 Cache
– MMU and FPU capabilities
– DMA-channel controllers
32 or 64MB of FlashEprom memory
128MB of shared SDRAM
128KB Backup SRAM and Calendar clock
I/O subsystem
3 * Ethernet 10/100TX auto-sensing ports
4 or 8 high-performance serial controllers:
– Asynchronous:
– high speed capability and HDLC for PPP
– Synchronous:
– HDLC, BSC, transparent modes
Software confi gurable mode for the eight serial ports: V10, V11, EIA530A, RS232/422/485/449/High Z
Redundancy link (RS422)
Console and JTAG/COP ports
Configurations
4 serial channels (pLinesES4)
8 serial channels (pLinesES8)
| Standard | Extended | Rugged | Conduction-cooled 71°C | Conduction-cooled 71°C | |
|---|---|---|---|---|---|
| Coating | Optional | Yes | Yes | Yes | Yes |
| Operat. Temp. | 0 to 55°C | -20 to 65°C | -40°C to 71°C (*) | -40°C to 71°C at the thermal interface (*) | -40°C to 85°C at the thermal interface (*) |
| Rec. airflow | 1 .. 2 m/s | 2 .. 3 m/s | 2 .. 5 m/s | - | - |
| Oper. HR% no cond. | 5 to 90% | 5 to 95% | 5 to 95% | 5 to 95% | 5 to 95% |
| Storage Temp. | -45°C to 85°C | -45°C to 85°C | -45°C to 100°C | -45°C to 100°C | -45°C to 100°C |
| Sinusoidal Vibr | 2G [20..2000]Hz | 2G [20..2000]Hz | 5G [20..2000]Hz | 5G [20..2000]Hz | 5G [20..2000]Hz |
| Random Vibr | 0.002g2 /Hz [10..2000]Hz | 0.002g2 /Hz [10..2000]Hz | 0.05g2 /Hz [10..2000]Hz | 0.1g2 /Hz [10..2000]Hz | 0.1g2 /Hz [10..2000]Hz |
| Shock 1/2 Sin. 11ms | 20G | 20G | 40G | 40G | 40G |
