The IC-PPC-VMEb based on one or two QorIQ® T2081 (or T1042) processors, offers unparalleled performance to VME legacy applications and provides ruggedized and highly secure solutions.
Superseding our IC-De6-VMEb, it ensures compatibility with existing equipments while offering increased embedded computing power.
The IC-PPC-VMEb board provides a flexible combination of interfaces offering a highly versatile open platform in a single slot VME to optimize weight, size, power and cost. This SBC has been designed to meet the needs of OEMs servicing the mil-aero and industrial market fields.
Processing Unit
• 1 or 2 * QorIQ® T2081(1.8 GHz)/T1042
(1.4 GHz) with:
• Up to 8 GB DDR3-ECC per CPU
• 128MB SPI Mirrorbit flash (with backup
device for recovery)
• 128/256MB of Mirror Flash per CPU
• 512KB of nvRAM per CPU
• Temperature sensors and monitoring per
CPU
• Calendar clock with supercap backup per
CPU
• Elapse Time Counter
• DC and Thermal monitoring
Storage subsystem
• 1 * eUSB slot for SSD Disk per CPU
Communication subsystem
• 7 * GigaEthernet ports
• 1 * L2+ Giga switch (QoS, VLAN, etc.)
• Up to 3*USB2 external ports
• 1 * RS232 and 2 * RS422 port per CPU
• GPIOs
I/O subsystem
• VME64x capability (option)
• 1 * XMC slot
• 1 * PMC/XMC slot
• 1 * Open FPGA for customer applications
Accessories
• Engineering kit for debug : JTAG/COP,
console
• 6U Rear Transition Module
| Standard | Extended | Rugged | Conduction-cooled 71°C | Conduction-cooled 85°C | |
|---|---|---|---|---|---|
| Coating | Optional | Yes | Yes | Yes | Yes |
| Operat. Temp. | 0 to 55°C | -20 to 65°C | -40°C to 71°C (*) | -40°C to 71°C at the thermal interface (*) | -40°C to 85°C at the thermal interface (*) |
| Rec. airflow | 1 .. 2 m/s | 2 .. 3 m/s | 2 .. 5 m/s | - | - |
| Oper. HR% no cond. | 5 to 90% | 5 to 95% | 5 to 95% | 5 to 95% | 5 to 95% |
| Storage Temp. | -45°C to 85°C | -45°C to 85°C | -45°C to 100°C | -45°C to 100°C | -45°C to 100°C |
| Sinusoidal Vibr | 2G [20..2000]Hz | 2G [20..2000]Hz | 5G [20..2000]Hz | 5G [20..2000]Hz | 5G [20..2000]Hz |
| Random Vibr | 0.002g2 /Hz [10..2000]Hz | 0.002g2 /Hz [10..2000]Hz | 0.05g2 /Hz [10..2000]Hz | 0.1g2 /Hz [10..2000]Hz | 0.1g2 /Hz [10..2000]Hz |
| Shock 1/2 Sin. 11ms | 20G | 20G | 40G | 40G | 40G |
